多圆盘过滤机

用于白水回收For white water recovery

滤盘直径Filter disc diameter (mm)

Φ2500

Φ3600

Φ4500

Φ5200

过滤盘数量Filter disc quantity (n)

4-12

6-16

8-20

10-20

过滤面积Filter area (m²)

7.5

15

26

32

主传动电机功率Main drive motor power（kw）

5.5-11

7.5-15

11-18.5

22-37

进口白水浓度Concentration of inlet white water (%)

0.35-0.45

出浆浓度Outlet concentration (%)

3-5

白水通过量White water throughput (m³/m²h)

1.6-4.0

用于浆浓缩For pulp thickening

滤盘直径Filter disc diameter (mm)

Φ2500

Φ3600

Φ4500

Φ5200

滤盘数量Number of filter disc quantity (n)

4-12

6-16

8-20

8-20

单盘过滤面积Filter area per Disc (m²)

7.5

15

26

32

主传动电机功率Main drive motor power（kw）

5.5-11

7.5-15

11-18.5

22-37

浆种Pulp type

OCC, chemical wood pulp, deinked pulp, straw pulp

进浆浓度Inlet consistency (%)

0.6-1.2

出浆浓度Outlet consistency (%)

8-12

生产能力 Production capacity (t/m².d)

0.5-1.2
